Page #4 background imageLoading...
Page #4 background image
SVT-4 PRO Bass Guitar Amplifier
4
Introduction
Congratulations!
You are now the proud owner of an Ampeg SVT-4 PRO bass
guitar amplifier. This versatile and powerful bass amplifier delivers up to 1600 watts of
unsurpassed quality, offering the classic vibrance of tubes, as well as contemporary features.
The SVT-4 PRO amplifier is an ideal companion to the Classic Series, Pro Series, or
PF cabinets, available separately.
Like all Ampeg products, your SVT-4 PRO amplifier is designed by musicians and built
using only the best of components. Each amplifier is tested to confirm that it meets our
specifications, and we believe that this amplifier is the absolute best that it can be. In order to
get the most out of your new amplifier, please read this manual before you begin playing.
Best of luck in all of your musical endeavors!
Sincerely,
The dedicated team at Ampeg
Features
• DUAL SEPARATE POWER AMPLIFIERS: Operate in true stereo or mono bridged mode
for even greater output power [pages 5–6, 12].
• BI-AMP CAPABLE: Adjustable crossover frequency control and low-to-high frequency
balance control allow you to fine-tune the bi-amp abilities of the amplifier [pages 6–7, 10].
• 5-POSITION MIDRANGE SELECTOR: Take your pick from the five center frequency
points available to get just the right midrange voicing [page 9].
• COMPRESSION CONTROL: Allows you to control the dynamics of the tonal response
characteristics from the power amp, from punch to compressed [page 8].
• 9–BAND GRAPHIC EQ: Use as a “second channel” for bass solos, or to shape the
sound to your own exacting standards. An independent level control allows you to adjust
the Graphic EQ volume [page 10].
• TUNER OUT JACKS: Two jacks – one on the front panel, one on the rear panel – allows
connection to an electronic tuner and provides an “always live” monitor feed, even when
the output is muted [pages 8, 13].
• SPEAKON JACKS: For more reliable connections at higher outputs and for mono
bridged connections (in addition to 1/4" speaker out jacks) [page 11].
• TRANSFORMER BALANCED LINE OUTPUTS: Independent level control. Two trans-
former balanced XLR and two balanced/unbalanced 1/4" output jacks – switchable stereo
or mono (one “wet”, one “dry” signal), pre– or post–EQ [page 12].
• STEREO EFFECTS LOOP: Connect effects here for increased intensity and quieter
operation [page 13].
• POWER AMP IN AND PREAMP OUT: Two separate loops, one for each channel:
a separate preamp may be connected to the Power Amp In jack and the Preamp Out
jack may be connected to a slave amp [page 12].
• FOOTSWITCH CONTROL: Use a footswitch to bypass/activate the Effects Loop and to
activate the Graphic EQ and the Mute feature [page 12].
• CIRCUIT BREAKER PROTECTION: A heavy duty resettable circuit breaker provides
protection against fault conditions [page 11].

Other manuals for Ampeg SVT-4 PRO

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ampeg SVT-4 PRO and is the answer not in the manual?

Ampeg SVT-4 PRO Specifications

Output Power IconOutput Power
output power rating mono-bridged at 4 ohms1600 Watts
output power rating mono-bridged at 8 ohms1200 Watts
output power rating 2 x at 2 ohms900 Watts
output power rating 2 x at 4 ohms625 Watts
output power rating 2 x at 8 ohms350 Watts
Tone Control Range IconTone Control Range
bass control range±12dB @ 50Hz
midrange control range±15dB @ selected frequency
treble control range+14dB / -19dB @ 5kHz
Graphic EQ IconGraphic EQ
graphic eq level±10dB
graphic eq range 33Hz±15dB
graphic eq range 80Hz±8dB
graphic eq range 150Hz±8dB
graphic eq range 300Hz±8dB
graphic eq range 600Hz±8dB
graphic eq range 900Hz±8dB
graphic eq range 2kHz±8dB
graphic eq range 5kHz±9dB
graphic eq range 8kHz±10dB
Switches IconSwitches
bright switch+6dB @2kHz
ultra high switch+6dB @ 5kHz
ultra low switch+2.5dB @ 50Hz -12dB @ 560Hz +1.5dB @ 5kHz
General Specifications IconGeneral Specifications
signal to noise ratio75dB typical
compression ratio10:1
tube complement12AX7 (3)
Power Requirements IconPower Requirements
domestic power requirements120VAC, 60Hz, 1.4kVA
export power requirements 100/115VAC50/60Hz, 1.4kVA
export power requirements 230VAC50/60Hz, 1.4kVA
Size and Weight IconSize and Weight
width19/17.4”
height with feet5.6”
depth15.5”
weight39.5 lbs
