27
Item Components Description Quantity
1 Connector Body 1 set
2 Bracket 1 pcs
3 Grommet 1 pcs
Rear Shell 1 pcs
Part 1: Plug Components
Part 1: Plug Cable Assembly
1 2 3
Step 1: Un-assemble rear attachments


Step 2: Wire stripping



