Part 3: 
After turn off the power, press the button and then pull out the plug horizontally in the direction shown below.
Pull out Plug
Button
Step 1: For end use, the separation active space requires is 67.5mm minimum.
Step 2: Do not deviate from the axis direction of the receptacle until it was separation complete, or it has a risk to
damage the connector.

X X X
