Amphenol SurLok Plus - Part 1: Package Contents; Part 2: Plug Assembly

8
Part 1: Package Contents
Part 2: Plug Assembly
1. Connector Body
1-1: O-Ring (not included when there is no sealing requirement)
2. Grommet (not included when there is no sealing requirement)
3. Backshell
1. Unscrew the backshell (grommet should remain within the backshell)
1
1-1
2 3
2. Slide the grommet/backshell onto the cable as shown
