• Inspect the DMM, test leads and accessories before every
use. Do not use any damaged part.
• Never ground yourself when taking measurements. Do not
touch exposed circuit elements or test probe tips.
• Do not operate the instrument in an explosive atmosphere.
• Exercise extreme caution when: measuring voltage >20 V
// current >10 mA // AC power line with inductive loads //
AC power line during electrical storms // current, when the
fuse blows in a circuit with open circuit voltage >1000 V //
servicing CRT equipment.
• Always measure current in series with the load – NEVER
ACROSS a voltage source. Check fuse first. Never replace a
fuse with one of a different rating.
• Remove test leads before opening the case.
SYMBOLS USED IN THIS MANUAL

Battery
�
Refer to the manual

Double insulated

Dangerous Voltage

Direct Current

Earth Ground

Alternating Current

Audible tone
I
Fuse

Canadian Standards
Association
P
Complies with EU
directives
Non-contact Voltage
MAKING MEASUREMENTS
Verify Instrument Operation
Before attempting to make a measurement, verify that
the instrument is operational and the battery is good. If
the instrument is not operational, have it repaired before
attempting to make a measurement.
