10
Overload protection: 600 Volts ac & dc.
Transient protection : 6kV (1.2/50μs surge)
AC Voltage
Range Frequency Accuracy
400.0mV
1)
50Hz – 500Hz ± (4.0% rdg + 5d)
4.000V, 40.00V, 400.0V 50Hz – 60Hz ± (2.0% rdg + 5d)
4.000V, 40.00V, 400.0V 60Hz – 500Hz ± (2.5% rdg + 5d)
600V 50Hz – 500Hz ± (3.0% rdg + 5d)
CMRR: >60dB @ DC to 60Hz, Rs=1kΩ
Input Impedance: 10MΩ, 30pF nominal
TRMS Response: 5% to 100% of Range
Crest Factor (ACD-6 TRMS-PRO): < 2.5 : 1 at full scale; < 5.0 : 1 at half scale
Overload protection: 600 Volts ac & dc.
Transient protection: 6.0kV (1.2/50μs surge)
1)
Selection by RANGE button manually, and is specified from AC 40mV (AC 60mV for True
RMS model ACD-6 TRMS-PRO) and up
ACA Current (Clamp-on)
Range Frequency Accuracy
1) 2) 3)
400.0A 50Hz – 60Hz ± (1.5% rdg + 5d)
1000A 50Hz – 60Hz ± (1.5% rdg + 5d*)
TRMS Response: 5% to 100% of Range
Crest Factor (ACD-6 TRMS-PRO): < 2.6 : 1 at full scale; < 5.2 : 1 at half scale
ACA Clamp-on jaws : AC 1000A rms continuous
1)
Add 8d to specified accuracy if reading is below 15% of Range
2)
Induced error from adjacent current-carrying conductor: < 0.06A/A
3)
Specified accuracy is for measurements made at the jaw center. When the conductor is not
positioned at the jaw center, position errors introduced are:
Add 1% to specified accuracy for measurements made WITHIN jaw marking lines (away
from jaw opening)
Add 4% to specified accuracy for measurements made BEYOND jaw marking lines (toward
jaws opening)
