Amprobe AMP-210 - Dimensions; Weight; Jaw Opening and Conductor Diameter; Maintenance and Repair

17
Dimension
(L x W x H)
8.82 x 3.03 x 1.46 in (224 x 77 x 37 mm)
for AMP-220 and AMP-320
8.62 x 3.03 x 1.46 in (219 x 77 x 37 mm)
for AMP-210 and AMP-310
Weight
254 g (0.56 lb) for AMP-220 and AMP-320 with batteries
installed
208 g (0.46 lb) for AMP-210 and AMP-310 with batteries
installed
Jaw opening
& conductor
diameter
1.37 in (35 mm) max for AMP-220 and AMP-320
1.18 in (30 mm) for AMP-210 and AMP-310
ELECTRICAL SPECIFICATIONS
Accuracy is ± (% reading digits + number of digits) or otherwise specified at
23°C ± 5°C.
Maximum Crest Factor < 2.5:1 at full scale & < 5:1 at half scale or otherwise
specified, and with frequency spectrum not exceeding the specified
frequency bandwidth for non-sinusoidal waveforms.
DC Voltage
Range Accuracy
600.0V ± (1.0 % + 5 LSD)
Input Impedance: 10 MΩ, 100 pF nominal
AC Voltage (with Digital Low-Pass Filter)
Range Accuracy
600.0V ± (1.0 % + 5 LSD)
Frequency: 50 Hz to 60 Hz
Input Impedance: 10 MΩ, 100 pF nominal
DC+AC Voltage (with Digital Low-Pass Filter)
(AMP-220 and AMP-320 only)
Range Accuracy
600.0V ± (1.2 % + 7 LSD)
Frequency: DC, 50 Hz to 60 Hz
Input Impedance: 10 MΩ, 100 pF nominal
PEAK-rms (AC V & AC A for AMP-220, AMP-310 and AMP-320 only)
Response: 80 ms to > 90 %
Continuity
Audible Threshold: ON at ≤ 10 Ω ; OFF at > 250 Ω
Response time: 32ms approx.
