Amprobe INSP-3 - Page 98

14
Volt Drop @15A=4.2%
(1.1% Hot + 3.1% Neut)
Loaded Voltage =116.4
Gnd Impedance = .27e
121.5 Vrms
60 Hz
Polarity OK
Common Mode: 0.79V
HotNeu Fault: 424A
HotGnd Fault: 850A
121.5 Vrms
60 Hz
Polarity OK
Fig. 1
Fig. 2
Fig. 3
