SYMBOLS
Caution! Refer to the
explanation in this
Manual
Complies with EU
directives
Conforms to relevant
Australian standards.
Do not dispose of this
product as unsorted
municipal waste.
Warning and Precautions
Do not operate the meter in explosive gas (material), combustible gas •
(material) steam or filled with dust.
The light sensor is calibrated to CIE standard incandescent lamp at 2856 °K •
and may give different readings for spectrums from other lamp types.
UNPACKING AND INSPECTION
Your shipping carton should include:
1 LM-200LED LED light meter
1 9 volt battery
1 Users Manual
If any of the items are damaged or missing, return the complete package to
the place of purchase for an exchange.
INTRODUCTION
The instrument measure the visible light from LED lamp or lighting source.
One LUX (Lumen) is the illumination from a one candela lamp perpendicular to
a surface one meter squared at a distance of one meter. One foot-candle (Fc) is
the illumination from a one candela lamp perpendicular to a surface one foot
squared at a distance of one foot.
OPERATION
Press the 1. button to turn power on or off
Remove sensor cap and place the sensor perpendicular to the light.2.
Select Illuminance scale and range for reading.3.
When done testing, replace the sensor cover to protect the filter and 4.
sensor.
