11
CONTINUITY CHECK
Continuity Threshold: Approx. <50
Continuity Indicator: 2.7 KHz Tone Buzzer.
Input Protection: 600V rms..
Function Ranges Resolution Accuracy
Cap
40.00nF 0.01nF ± (5%+ 0.4nF)
400.0nF 0.1nF
± (2.9%+ 5D)
4.000µF 0.001µF
40.00µF 0.01µF
400.0µF 0.1µF
Measuring Time: <30sec. (400.0µF range),
<10sec. (40.0µF range), <3sec. (other
range)
Overload protection: 600V rms.
Function Ranges Resolution Accuracy
Hz
40.00Hz 0.01Hz
± (0.3%+ 5 D)
400.0Hz 0.1Hz
4.000KHz 0.001KHz
40.00KHz 0.01kHz
Sensitivity: > 10Vp-p (40KHz range)
> 1.5Vp-p (other range)
The signal must have positive and negative waveform
of a cycle.
Max. Sensitivity: 600V rms.
Overload protection: 600V rms.
Function Ranges Resolution Accuracy
% 0.1 - 99.9% 0.1%
± (0.5%+ 10
D)*
*: 30% ≦ Duty ≦ 70%,
