3
➊
Relative Humidity display
Temperature, Wet Bulb, Dew Point
display
Min/Max indicator
➍
Dew point and Wet bulb indicator
Low battery indicator
➏
Data Hold Indicator
Humidity indicator
Temperature unit indicator
LCD Display
1
2
3
7
8
9
4
5
6
1
2
4
3
8
6
7
5
➊
Large LCD digital dual display
Extended probe for easy target access.
Tripod mountable
➍
ON/OFF pushbutton to turn the unit on
and off
Backlight pushbutton for easy use in
dark places
➏
Temperature (°C& °F units selectable)/
Calibration pushbutton
Data Hold pushbutton to stop on the
last reading
DP/WB pushbutton for dew point or wet
bulb.
RST/Min/Max pushbutton to display the
minimum or the maximum of the actual
measurement. Also use to reset the
Min/Max value.
