EN-10
DAB antenna
A
B
C
DE
1
3
5
7
24
68
1
3
5
7
24
68
1
4
36
2
5
1
4
36
2
5
1
4
7
6
3
2
5
8
Mute
BATTERY +
IGNITION/ACC
POWER GROUND
ANTENNA REMOTE
ILLUMINATION
SWRC GND
SWRC+
C5
C6
D1
D4
MIC -
MIC +
NO.NO.
connection step:
First:Insert simultaneously the
A&B connector
Second:Insert simultaneously
the C&D connector
Radio Antenna
DAB Antenna
Wiring Diagram
DAB antenna set-up
Position the antenna
- on the windscreen inside the car
- to the right of the driver for safety reasons
- on a xed surface; avoid moving parts such
as doors, windows, etc.
- vertically and half way up the windscreen,
out of the driver's eld of vision.
A detailed version of the assembly notes is
available on our website.
Please do not cut the yellow tape on the DAB
antenna.
You can download the complete assembly
instructions from www.ams-diffusion.com
