INSTALLATION, OPERATION

& MAINTENANCE

INSTRUCTIONS

9013-0001 (3/08)

WELL-X-TROL

®

WELL-X1

™

INSTALLER: LEAVE THIS MANUAL WITH THE OWNER

IMPORTANT GENERAL SAFETY INFORMATION - ADDITIONAL SPECIFIC SAFETY ALERTS APPEAR IN THE FOLLOWING INSTRUCTIONS.

READ CAREFULLY THE PRODUCT INSTALLATION, OPERATING AND MAINTENANCE MANUAL. FAILURE TO FOLLOW

THE INSTRUCTIONS AND WARNINGS IN THE MANUAL MAY RESULT IN SERIOUS OR FATAL INJURY AND/OR PROPERTY DAMAGE,

AND WILL VOID THE PRODUCT WARRANTY. THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED PROFESSIONAL. FOLLOW ALL

APPLICABLE LOCAL AND STATE CODES AND REGULATIONS, IN THE ABSENCE OF SUCH CODES, FOLLOW THE CURRENT EDITIONS OF

THE NATIONAL PLUMBING CODE AND NATIONAL ELECTRIC CODE, AS APPLICABLE.

This is the safety alert symbol. It is used to alert you to personal injury hazards. Obey all safety instructions that follow this symbol to

reduce the risk of possible injury or death as well as property damage.

West Warwick, Rhode Island 02893

Table of Contents

Questions and Answers:

C
claire86Aug 15, 2025
What to do if there is no water at fixtures in my Amtrol Water Heater?
- D
  Dorothy LunaAug 15, 2025
  If there's no water coming out of your Amtrol Water Heater fixtures, potential causes include a power outage (check the circuit breaker and wiring), an obstructed water line (ensure shut-off valves are open and inspect filtration equipment), a faulty pump (repair or replace as needed), an open drain or relief valve (ensure they are closed), a leak in the plumbing (check the piping), or an error (consult the Error Code section).
A
Andrew PriceAug 18, 2025
Why won't my Amtrol WELL-X-TROL Water Heater pump shut off?
- K
  Keith WillisAug 18, 2025
  If your Amtrol Water Heater pump won't shut off, it could be due to several reasons. The pressure setting might be too high, requiring a decrease until the pump can reach cut-out. There might be an obstruction in the pump water line; ensure no shut-offs are closed between the pump and the Well-X1™. It could also be a pump problem, so inspect the well pump condition and sizing if the pump cannot reach a reasonable cut-out setting. A failed control might also be the cause, in which case it should be replaced.
A
Allen RobinsonAug 21, 2025
How to fix low water pressure in my Amtrol Water Heater?
- T
  Tammy HenryAug 21, 2025
  If you're experiencing low water pressure with your Amtrol Water Heater, several factors could be the cause. The pressure setting might be too low, requiring adjustment of the pump cut-in and cut-out settings as described in the manual. A water line obstruction could be present, so ensure shut-off valves are open and check filtration equipment. A faulty pump, incorrect wiring, or a pressure setting out of range could also be responsible. Check the well pump and pump wiring, and reduce pressure settings within the pump's capacity.
H
hendersonjoyceAug 25, 2025
Why does the relief valve on my Amtrol Water Heater keep discharging?
- J
  Jason BrownAug 25, 2025
  If the relief valve on your Amtrol Water Heater discharges, it could be due to an over-pressure condition; refer to the "Pump will not shut off" section for troubleshooting. Alternatively, the relief valve itself might be faulty. If the pressure is below 100 psi, the relief valve should not open; replace it if it does.
A
Alexandra WardAug 27, 2025
What to do if there is no pressure but the pump runs on my Amtrol WELL-X-TROL?
- E
  Elizabeth CameronAug 27, 2025
  If your Amtrol Water Heater pump is running but there's no pressure, it could be due to a few reasons. If you have jet pumps, the pump may not be primed, so prime the pump and restart it. Another possibility is a failing well pump, which may need repair or replacement. Incorrect wiring could also be the cause, so check the pump wiring.
M
Marie HernandezAug 30, 2025
Why is my Amtrol WELL-X-TROL pump cycling rapidly?
- W
  william54Aug 30, 2025
  If you're experiencing rapid pump cycling with your Amtrol Water Heater, it could be due to a differential that is too narrow; check the sizing for the intended operating range or spread the differential to obtain proper pump run time. It may also be caused by an improper precharge, so adjust the air pressure 2 psi below the cut-in setting. In some cases, it could be a failed tank that needs replacement.
M
mvillaSep 2, 2025
Why won't my Amtrol WELL-X-TROL Water Heater pump turn on, even though the display is lit?
- R
  Richard LyonsSep 2, 2025
  If your Amtrol Water Heater pump will not turn on but the display is illuminated, the issue could stem from several causes. There might be an error encountered, so refer to the Error Code section for possible causes. The pump itself could be faulty, requiring repair or replacement. A failed control might also be the reason, necessitating replacement. Additionally, the pressure sensor line could be blocked, so remove and clean it. Loose or faulty wiring could also be the culprit, so check the pump wiring.
T
Todd McdanielSep 5, 2025
Why will the display not illuminate on my Amtrol WELL-X-TROL Water Heater?
- T
  Teresa ThomasSep 5, 2025
  If the display on your Amtrol Water Heater will not illuminate, the issue could stem from a circuit breaker or switch being off; check the breaker and service switch. It could also be due to faulty or loose wiring, so check the line supply wiring. In some cases, it may be a failed control that needs replacement.
J
james60Sep 8, 2025
Why is there sediment or discoloration in my Amtrol WELL-X-TROL Water Heater water?
- E
  Elizabeth BrownSep 9, 2025
  If you notice sediment or discoloration in the water from your Amtrol Water Heater, it's likely due to poor water quality. To address this, install proper treatment equipment and drain and flush the tank according to the instructions in this manual.
J
Jason OrtizSep 12, 2025
Why am I experiencing intermittent water interruption with my Amtrol Water Heater?
- K
  Kenneth MilesSep 12, 2025
  If you are experiencing intermittent water interruption with your Amtrol Water Heater, it could be due to a tank precharge that is too high; adjust the air pressure 2 psi below the cut-in setting. It may also be due to a recurring error; see the Error Code section for possible causes.

Amtrol WELL-X-TROL Specifications

General

Material	Steel
Maximum Pressure	150 PSI
Connection Type	NPT
Orientation	Vertical
Capacity	119 Gallons
Certification	NSF Standard 61

Summary

General Safety Information

Components

Installation and Sizing Considerations

Standard Operation

Sizing the Well-X1™ for standard systems with a 20 psi differential.

Constant Pressure Mode

Selecting the Well-X1™ for constant pressure systems with narrow differentials.

Installation Considerations

Location

Specifies conditions for indoor and outdoor installation of the Well-X1™.

Orientation

Details vertical installation requirements and site considerations for the Well-X1™.

Plumbing

Wiring

Startup & Adjustment

Pump Protection and Diagnostics

Troubleshooting

Replacement Parts

Pressure Adjustment

Precharge Adjustment

Adjusting tank precharge based on cut-in setting changes for optimal performance.
