3. COMPONENTS
The Well-X1
™
combines all the standard well tank components in a single, easy to install package. The pressure tank,
control and tank fittings are factory-installed. After removing from the carton, inspect the Well-X1
™
for damage and
ensure all components are present.
CONDUIT HOLES
PUMP & POWER WIRES
AIR CHARGING
VALVE
RELIEF VALVE
MOUNTING
KNOB
WATER
CONNECTIONS(2)
CONTROL
PRESSURE
TANK
DRAIN
TANK
TUBING
PRESSURE SENSOR
TUBING
MOUNTING
BRACKET
COVER

Amtrol WELL-X-TROL Specifications

General

Material	Steel
Maximum Pressure	150 PSI
Connection Type	NPT
Orientation	Vertical
Capacity	119 Gallons
Certification	NSF Standard 61
