Installing Wall-Mount (MXD) Panels
30
Modero S Series Touch Panels - Installation & Hardware Reference Manual
Installation Dimensions
MXD-1001-L Dimensions
Detailed specifications drawings for the MSD-1001-L are available to download from www.amx.com.
FIG. 28
MST-1001-L
Notes:
Dimensions in parenthesis are in millimeters
Additional detailed installation and product drawings are available to view/download at www.amx.com
