DEMO MANUAL DC2787A
Rev. 0
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
25 4 R2, R36, R53, R56 RES.,AEC-Q200,1 OHM,5%,1/10W,0603 VISHAY, CRCW06031R00JNEA
26 43 R5, R10-R12, R14,
R20, R24, R32, R33,
R35, R40, R41, R45,
R47, R50, R51, R76,
R226-R231, R240, R241,
R246, R252, R254-R256,
R258, R264, R266-R268,
R270, R271, R273-R276,
R278, R279
RES.,0 OHM,1/10W,0603 VISHAY, CRCW06030000Z0EA
27 1 R6 RES.,AEC-Q200,1M OHM,1%,1/8W,0805 PANASONIC, ERJ6ENF1004V
28 1 R8 RES.,34k OHMS,1%,1/10W,0603 NIC, NRC06F3402T
29 9 R9, R13, R22, R28, R49,
R60, R62, R272, R277
RES.,AEC-Q200,10k OHMS,1%,1/10W,0603 VISHAY, CRCW060310K0FKEA
30 4 R15, R37, R52, R57 RES.,100k OHMS,1%,1/10W,0603 VISHAY, CRCW0603100KFKEA
31 4 R16, R48, R64, R68 RES.,53.6k OHMS,1%,1/10W,0603,AEC-Q200 VISHAY, CRCW060353K6FKEA
32 4 R17, R43, R70, R71 RES.,AEC-Q200,6.81k OHMS,1%,1/8W,0805 VISHAY, CRCW08056K81FKEA
33 1 R18 RES.,3.74k OHMS,1%,1/10W,0603 PANASONIC, ERJ3EKF3741V
34 4 R23, R75, R244, R259 RES.,AEC-Q200,60.4k OHMS,1%,1/10W,0603 VISHAY, CRCW060360K4FKEA
35 4 R25, R66, R245, R248 RES.,AEC-Q200,4.32k OHMS,1%,1/10W,0603 VISHAY, CRCW06034K32FKEA
36 1 R26 RES.,182k OHMS,1%,1/10W,0603,AEC-Q200 PANASONIC, ERJ3EKF1823V
37 1 R27 RES.,20k OHMS,5%,1/10W,0603,AEC-Q200 NIC, NRC06J203TRF
38 1 R29 RES.,80.6k OHMS,1%,1/10W,0603 VISHAY, CRCW060380K6FKEA
39 2 R30, R247 RES.,0.2 OHM,1%,1/2W,2010,SENSE, AEC-Q200 VISHAY, WSL2010R2000FEA
40 1 SW1 SWITCH,SLIDE,DPDT,0.3A,6VDC,PTH C&K, JS202011CQN
41 4 U1-U4 IC, Hybrid Step-Down Synchronous Controller QFN-32 ANALOG DEVICES, LTC7821EUH#PBF
42 1 U7 IC, SYNCHRONOUS STEP-DOWN CONVERTER ANALOG DEVICES, LTC3630AEMSE#PBF
Additional Demo Board Circuit Components
1 0 C16, C46, C48, C51,
C160, C171, C172,
C290-C295
CAP., OPTION, 0603
2 0 Q1A, Q1A1, Q11A,
Q11A1, Q22, Q22A,
Q22A1-Q22A3, Q25, Q26,
Q29, Q30, Q33, Q34, Q37
XSTR., OPTION, MOSFET N-CH, PPAK SO-8
3 0 Q23, Q24, Q27, Q28,
Q31, Q32, Q35, Q36
XSTR., OPTION, MOSFET N-CH, PG-TDSON-8
4 0 R3, R31, R34, R44, R46,
R65, R74, R234, R235,
R250, R251, R253,
R262, R263, R265
RES., OPTION, 0603
5 0 RN1-RN4 THERMISTOR, OPTION, 0603
PARTS LIST
