7
DEMO MANUAL DC2787A
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 8 C1, C6, C68-C70, C74,
C153, C154
CAP.,33uF,ALUM. ELECT.,80V,20%,10x10.2mm SMD,
RADIAL,AEC-Q200
PANASONIC, EEHZA1K330P
2 26 C2, C3, C7, C47, C49,
C56, C58, C59, C71-C73,
C85-C88, C103-C105,
C109, C119, C203,
C206-C210
CAP.,2.2uF,X7R,100V,10%,1210 AVX, 12101C225KAT2A
3 16 C4, C5, C12, C13, C15,
C17, C37, C91, C95,
C107, C166, C169, C174,
C175, C287, C288
CAP.,0.1uF,X7S,100V,10%,0603 TAIYO YUDEN, HMK107C7104KA-T
4 8 C8, C14, C40, C106,
C108, C165, C167, C170
CAP.,0.22uF,X7R,25V,10%,0603 YAGEO, CC0603KRX7R8BB224
5 4 C9, C102, C164, C173 CAP.,0.47uF,X7R,25V,10%,0603 AVX, 06033C474KAT2A
6 113 C10, C11, C18-C25,
C28-C36, C38, C41, C43,
C60-C67, C75-C83, C90,
C92-C94, C98-C101,
C111-C118, C121-C150,
C176-C202, C216
CAP.,10uF,X7S,100V,10%,1210 MURATA, GRM32EC72A106KE05L
7 4 C26, C120, C157, C158 CAP.,2.2uF,X5R,25V,10%,0603 MURATA, GRM188R61E225KA12D
8 5 C27, C50, C96, C159,
C162
CAP.,1uF,X7R,25V,10%,0603,AEC-Q200 MURATA, GCM188R71E105KA64D
9 1 C39 CAP.,4.7nF,X7R,25V,10%,0603 AVX, 06033C472KAT2A
10 8 C42, C44, C57, C84, C89,
C97, C152, C155
CAP.,150uF,ALUM./OS-CON,16V,20%,8x6.9mm
SMD, RADIAL
PANASONIC, 16SVPC150M
11 4 C45, C110, C156, C215 CAP.,27pF,C0G,250V,5%,0603 MURATA, GQM1875C2E270JB12D
12 2 C52, C53 CAP.,22uF,X5R,25V,10%,1210 MURATA, GRM32ER61E226KE15K
13 1 C54 CAP.,0.047uF,X7R,25V,10%,0603 AVX, 06033C473KAT2A
14 1 C55 CAP.,220pF,C0G,50V,5%,0603 AVX, 06035A221JAT2A
15 4 C255, C257, C259, C261 CAP.,4.7uF,X5R,16V,10%,0603 MURATA, GRM188R61C475KE11D
16 4 C256, C258, C260, C262 CAP.,4.7uF,X5R,50V,10%,0805 MURATA, GRM21BR61H475KE51L
17 12 D1-D6, D11-D16 DIODE,SCHOTTKY,40V,250mW,SOD-323 CENTRAL SEMI., CMDSH-4E TR Lead Free
18 4 L1-L4 IND.,2uH,PWR. SHIELDED,20%,40A,1.34mOhms,19
.69x19.55x10.67mm
, SMD,AEC-Q200
COILCRAFT, SER2011-202MLB
19 1 L5 IND.,68uH,PWR, SHIELDED,20%,0.74A,0.42
OHM,2424, LPS6225
COILCRAFT, LPS6225-683MRB
20 4 Q1, Q2, Q11, Q13 XSTR.,MOSFET, N-CH,80V,40A,TSDSON-8 FL INFINEON, BSZ070N08LS5
21 8 Q3-Q6, Q9, Q10, Q15,
Q16
XSTR.,MOSFET, N-CH,40V,98A,TDSON-8 INFINEON, BSC032N04LS
22 4 Q7, Q8, Q12, Q14 XSTR.,MOSFET, N-CH,40V,100A,TDSON-8 FL INFINEON, BSC014N04LSI
23 2 Q20, Q21 XSTR.,MOSFET, N-CH,40V,TO-252 (DPAK) VISHAY, SUD50N04-8M8P-4GE3
24 8 R1, R7, R19, R38, R42,
R58, R59, R61
RES.,1k OHM,1%,1/10W,0603 VISHAY, CRCW06031K00FKEA
To Next Page
