11
HAVING TROUBLE WITH YOUR SOUND SYSTEM?
CONDITION POSSIBLE SOLUTIONS
No Sound (Power LED: OFF)
• Turn POWER knob clockwise to turn ON
• Check battery level, charge battery, or plug in AC cord
No Sound (Power LED: ON
• Check your source audio and turn up volume of source audio
• Make sure all cables are completely plugged in
• Turn up volume control
Wireless Mic will not Connect to System
• Check battery level of microphone
• Un-pair all microphones from the system then re-pair the
microphones
Connected Wireless Mic but No Sound
(Solid Green LED)
• Check the Mute button on the microphone or belt pack
• Raise volume on the microphone and system
• Check battery level of microphone and system
Poor Wireless Range /
Poor Wireless Audio Quality
• Check battery level of microphone and system
• Re-position system away from any possible interference sources
• Minimize obstructions between the system and wireless
microphone
• If wireless range continues to be poor, call Anchor Audio
Tech Support
Distorted Sound
• Check battery level, charge battery, or plug in AC cord
• Lower system volume
• Lower source audio volume
• Wireless belt pack - ensure Mic and/or Line Level setting is correct
Excessive Feedback (Squelching)
• Lower the volume on the microphone (handheld or belt pack)
• Do not stand within at least 10 feet in front of the speaker with
the mic(s)
Excessive Hum or Noise
• Use shielded cables
• Use a balanced microphone
TECHNICAL SPECIFICATIONS
Rated Power Output 30 watts AC/DC
Max SPL @ Rated Power 100 dB @ 1 meter
Frequency Response 100 Hz - 15 kHz ± 3 dB
Mircrophone Wireless Frequency 1.9 GHz DECT
Microphone Wireless Range 300’ line of sight
Line Input Line level, 3.5 mm
Microphone Input 1/4” phone, Lo-Z
Line Output Line level, 3.5 mm
Speaker Type 4.5” neodymium woofer
Batter y Type 10 ‘AA’ alkaline
Dimensions (HWD)
7” x 6” x 3.5”
(17.8 x 15.2 x 8.9 cm)
Weight 2.5 lbs / 0.45 Kg
(Specifications Subject to Change Without Notice)
