7
BASIC SYSTEM OPERATION
1. Plug the AC power cord into a wall power outlet or operate the unit using battery power.
If using battery power, ensure the batteries are fully charged.
2. Position the speaker to face your audience.
3. If you are using a wired microphone, plug the microphone into the ¼ MIC port.
4. To use an external audio device, plug one side of a 3.5mm cable into the device and the
other side of the cable into the LINE IN port.
5. To turn the Mini on, rotate the OFF knob clockwise. The Status light will turn red.
Note that this knob also controls the main volume of the speaker. Adjust as needed.
6. To pair or unpair your wireless microphones, see Wireless Microphone section.
You can use the Line In jack to play music or pre-recorded material through the Mini. The
Mini’s volume knob controls both the audio source and microphone levels. The volume can
also be controlled using the source audio’s volume controls.
1. Connect a 3.5 mm (mini plug) to the line or headphone output of your audio source.
2. Connect the other end of the 3.5 mm (mini plug) to the Line In port on the Mini back panel.
3. Adjust the volume of the external audio source as needed using the controls on the external
audio source or by adjusting the OFF knob on the Mini, which controls the master volume.
CONNECTING AN EXTERNAL AUDIO DEVICE
Made in the USA
POWER
VOLUME
Master Control
INPUT
Wired Accessories connect
laptops, audio devices
INPUT
Wired
Microphones
MIC BOOST
Increases overall
microphone volume
WIRELESS RECEIVER
*If equipped
BLUETOOTH
