BLOWER ASSEMBLY:
ELECTRICAL ASSEMBLY:
No. No.Description Description
1
2
3
4
No. No.Description Description
1
2
3
4
6
Propeller Cage
Motor
Propeller
Safety screen
Electronic box cover
PCB
Capacitor
Electronic box base
Electronic box bracket
5
LED driver
19
