Installation
STEP 12
Install Filters
To install lters, follow four steps below (See Fig #23):
• Angle the lter into slots at the back of the hood.
• Push the button on handle of the lter.
• Release the handle once the lter ts into a resting position.
• Repeat to install all lters.
Cleaning Filters
IMPORTANT: Drain oil from spacers, lters, oil tunnels, oil containers before oil and residue overow!
• Remove all spacers, lters, grease tray, and oil containers and discard oil and residue.
• Wash with warm soapy water. NOTE: Stainless steel lters, spacers and oil tunnel are top rack dishwasher safe.
• Dry thoroughly before replacing and follow directions for installation in reverse.
• Filters should be cleaned after every 30 hours of use.
• Should lters wear out due to age and prolonged use, replace with a new lter.
Fig #23
