13
PRODUCT MANUAL
46/50ST Below Deck Compact Motor
™
Negative (
-
)
Terminal BLACK
M8 Thread
Positive (
+
)
Terminal RED
M8 Thread
Control cable
(connection to push button)
Thermal sensor wires
Drain port tting
with drain tube
Motor Detail
