PRODUCT MANUAL
46/50ST Below Deck Compact Motor
™
12
The positive cable (+RED) must be
connected to positive terminal of
the motor.
INCORRECT POLARITY WILL
CAUSE PERMANENT DAMAGE TO
THE MOTOR AND INVALIDATE
THE WARRANTY!
WARNING
PUSH
BUTTON
[A1]
CONTROL
CABLE
[A10]
WINCH
MOTOR
[1]
THERMAL
SENSOR
WIRES
CIRCUIT BREAKER
CONTROLLER
[A11]
BATTERY
Wiring Diagram
