Anet A8 - Page 11

Attention：Leave vacancy between belt fixation clamp and
hot bed fixed plate for belt positioning.
Before Assembly After Assembly
Step 7
Step 8
Item
1
2
3
4
5
6
1
2
4
4
4
4
QTY.Name of parts
Step 6
Y axis Guide rod
Guide rod back up plate
Front plate
M3*18 screw
M3 Nut
Item
1
2
3
1
2
4
QTY.Name of parts
Hot bed fixed aluminum plate
Y axis belt fixation clamp
M4*14 screw
M3
M3*18
M4*14
Before Assembly After Assembly
Y Guide rod 380mm
Attention: Belt is for X&Y axis transmitting .Cut the length you need
to each transmission shaft. The belt is 1.5m in total and 10-20cm left
after installation.
Attention: Please diagonally tighten the screws when
all are in there place.
Before Assembly After Assembly
Step 9
Step 10
Item
1
2
3
1
1
16
QTY.Name of parts
Step 7
Step 8
M4*8 screw
Item
1 1
QTY.Name of parts
Belt
M4*8
Before Assembly
After Assembly
page 16 page 17
