66
2.Ajust concentricity
Z axis left screw support Z axis right screw support
Z motor & Flexible bearing Z motor screw locking sequence
1. Click to adjust Z axis to move ( Position → Z pos.Fast → +/- ) . If it cannot move
smoothly, you need to adjust the unsmooth side’s screw support. Try to keep them at
the same height.
2. We can also tight/loose the Z motor screw according to requirments. This is to correct
the deviation in the first time installation. Please take steps as follows to lock screws,
position all screws first and finally tighten them all.
