4
SET UP REQUIREMENTS
WHAT’S IN THE BOX
1
Nursery Unit
2
Stand (for Nursery Unit)
3
Sensor Pad
4
CR2450 Battery
(for Sensor Pad)
WHAT YOU NEED
• Hardboard, if the cot does not
have a firm surface
(see ‘IMPORTANT’ note - Step 1)
• 2 x AAA batteries (for Nursery Unit)
• Posidrive screwdriver
3
4
1
2
1 SETTING UP THE SENSOR PAD
e Sensor Pad is designed to detect subtle baby movements on the surface of the
mattress.e alarm will only sound if NO movement is detected for 20 seconds.
1
2
1. Remove the battery cover
and insert the battery
face with + face up
2. Replace the battery cover,
align 2 dots and click
to secure
Correct positioning
for slatted base
3
3. Remove the mattress from
the cot, place Sensor Pad
- Angelcare® logo side
up - on base in approximate
centre of mattress. It should
be centred on the hardboard
if your cot requires a
hardboard support (see
‘IMPORTANT’ note below)
4. Replace the mattress
