Read all the instructions before using this product;
This device should be supervised when used around children;
Do not put fingers into the electric vehicle connector;
Do not use the product when the charging cable has been damaged or frayed;
Do not use this product if the enclosure or the EV connector is broken, cracked,
open, or shows any other indication of damage;
The whole installation should be operated by qualified professional electrician;
Be careful! Any incorrect operation may cause life danger, injury or equipment
damage. The manufacturer would refuse to accept any claim arising therefrom.
Please make sure this instruction manual is fully understood and the specified
conditions are met before any operations of the EV charger;
Please do not operate under any circumstances that may cause electric leakage;
Changes or modifications to this unit not expressly approved by the part responsi-
ble for compliance could void the user’s authority to operate the equipment;
This equipment complies with FCC radiation exposure limits set forth for an rolled
environment.
This equipment should be installed and operated with a minimum distance of 20cm
between the radiator and your body.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: This manual contains important instructions for AC charger series that
shall be followed during installation, operation and maintenance of the unit.
1. SAFETY TIPS
USER MANUAL 2
SAVE THESE INSTRUCTIONS
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
CONTENTS
USER MANUAL
CONTENTS
1. Safety Tips…………………………………………………………………………………………………………………2
2. Important Information ………………………………………………………………………………………………3
2.1 Specified use ………………………………………………………………………………………………………3
2.2 About this Manual ………………………………………………………………………………………………3
3. Use of Products…………………………………………………………………………………………………………4
3.1 Product Appearance Size ……………………………………………………………………………………4
3.2 Product Appearance Introduction ………………………………………………………………………4
3.3 Product Performance Description ………………………………………………………………………5
3.4 LED Indicator Instruction ……………………………………………………………………………………6
3.5 Equipment Parts List……………………………………………………………………………………………6
4. Operation Guide…………………………………………………………………………………………………………7
4.1 Operation Steps ……………………………………………………………………………………………………7
5. Wallbox Installation Method………………………………………………………………………………………9
5.1 Wallbox Rendering ………………………………………………………………………………………………9
5.2 Fixing Cover Installation Drawing ………………………………………………………………………9
5.3 Gun Holder Installation Drawing ………………………………………………………………………10
5.4 Installation Environment Requirements……………………………………………………………10
5.5 Power Supply Requirements ……………………………………………………………………………10
6. Troubleshooting………………………………………………………………………………………………………11
6.1 Troubleshooting Table ………………………………………………………………………………………11
7. Maintenance……………………………………………………………………………………………………………13
7.1 Maintenance………………………………………………………………………………………………………13
7.2 Important Matters ……………………………………………………………………………………………13
7.3 After sales information ……………………………………………………………………………………16
