Anker A2934 - Product Performance Description; LED Indicator Instruction; Equipment Parts List

3. USE OF PRODUCTS
USER MANUAL 5
3.3 Product Performance Description
Product Characteristics
Protection Characteristics
Over Voltage Protection
Under Voltage Protection
Over Load Protection
Over Temperature
Protection
Ground Protection
Leakage Protection
Product Item
Output Power
Operating Current
Current Adjustability
Installation Method
Operating Voltage
Operating Frequency
Cable Length
Indicator
User Interface
Charging Method
Appearance Size
Product Weight
AC Input Plug
Connector Type
A2934
7.6kW
32 A（Max）
16A-20A-24A-32A
Portable/Wallbox
L1 /L2 /PE；240 Vac(±15 %)
60Hz±1Hz
NEMA 14-50P
Type 1(SAE J1772)
7.5m(25ft)
3-Color Indicator
1.3inches OLED Screen
Plug and Charge
297 mm X 106.6 mm X 53.8mm
＜4.2kg
Input Voltage＞120 %, relay is o
Input Voltage＜80 %, relay is o
CCID20, leakage, the relay was o
Output Current＞110 %, relay disconnected, the power
supply needed to be cut o and restored
The ground wire is not detected or the ground wire is
disconnected during charging. The relay is disconnected.
When the temperature of the main board reached
85 ℃ , the power was reduced to 50%, and it was turned
3. USE OF PRODUCTS
USER MANUAL 6
No.
1
2
3
4
5
6
7
8
9
Charging Status
Standby
Insert the Plug
Charging
C P Abnormal
Over voltage/Under voltage
Ground Fault
Over-current Protection
Leakage Protection
Over-temperature Protection
Indicator Color
Blue
Green
Green
Red
Red
Red
Red
Purple
Purple
Indicator Status
Always on
Always on
Flashing
Always on
Flashes once every 1S
Flashes once every 2S
Flashes once every 4S
Flashes once every 1S
Flashes once every 2S
No.
1
2
3
4
5
6
7
Equipment Parts
AC Charging Pile
Fixing Cover
Gun Holder
Screw
Expandable Rubber Stopper
Certification
User Manual
Quantity
1
1
1
7
7
1
1
3.4 LED Indicator Instruction
3.5 Equipment Parts List
Reliability
MTBF
Warranty
Safety Standard
100 , 000H
2Years
UL2594, UL2231-1/-2, UL1998, UL991, UL2251
Environment Characteristics
Operating Temperature
Operating Humidity
Operating Altitude
Protection Degree
-30℃ ~ +50℃（-22℉~+122℉）
5 % ~ 95 % RH
＜2000 m
TYPE 4 / IP66
Storage Temperature -35℃ ~ +80℃（-31℉~+176℉）
