This product must be grounded. If it should malfunction or break down,
grounding provides a path of least resistance for electric current to reduce
the risk of electric shock. This product is equipped with a cord having an
equipment grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded
in accordance with all local codes and ordinances.
4. OPERATION GUIDE4. OPERATION GUIDE
USER MANUAL 8
4.1 Operation Steps
Plug the charger into the socket
Adjust charging time according to personal time
Time Button(adjust reservation time)
Operating Status
Operating Temperature
Operating Voltage
Power Quantity
( 16 A、20 A、24 A、32 A)
Set the charging delay
Indicator
Connect
Charge
Current Button(Adjust current level)
Adjust the charging
current according
to the power
supplycurrent
of the socket
Adjust
charging
parameter
Specification of Switch and Socket
For power safety, add overcurrent protection device/circuit breaker at the
product input.
Power
7kW
Current
32A(Max)
Switch/Socket
40A(2P leakage protector)/32A Socket
1
2
No plug
Wait
kwh
Power
240V
32A
GROUNDING INSTRUCTIONS
WARNING
Open the charging
seat and confirm
that there is no
foreign matter
Hold the charging
gun and connect
the electric vehicle
After charging,
remove the
charging gun
6
4
5
USER MANUAL
7
Improper connection of the equipmentgrounding conductor is
able to result in a risk of electric shock. Check with a qualified
electrician or serviceman if you are in doubt as to whether the
product is properly grounded. Do not modify the plug provided
with the product if it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
78℉
3
Quick Start
Connect to
Start Charging
The charging gun is directly
inserted into the vehicle
charging base, and the
charging starts
Press the car remote
control to unlock and
stop charging
No plug
To Next Page
Loading...
