USER MANUAL 10
5. WALLBOX INSTALLATION METHOD
5.2 Fixing Cover Installation Drawing
［A］ Socket
［B］ Charging Pile
［C］ Fixing Cover
［D］ Wall
［E］ Plug
［F］ Gun Holder
［G］ Charging Gun
5.1 Wallbox Rendering
5. WALLBOX INSTALLATION METHOD
5.3 Gun Holder Installation Drawing
5.4 Installation Environment Requirements
E
C
A
D
B
The power supply mode of the portable AC charger is AC single-phase power supply,
and the input electrical requirements are:
5.5 Power Supply Requirements
USER MANUAL 9
A
E
F
G
B
C
D
As shown in the above figure, place the fixing cover on the wall at a proper height,
mark the hole location on the wall with a pencil, and use an impact drill to drill three
φ7 holes on the wall according to the hole marking, and drill three φ8 expansion
rubber plugs in the three holes. Finally, place the wall hanging shell on the wall, align
the fixing holes of the fixing cover with the wall holes, and fasten them with φ5
tapping screws.
●
As shown in the above figure, place the gun holder on the wall at a proper
height, mark the hole location on the wall with a pencil, and use an impact drill
to drill four φ7 holes on the wall according to the hole marking, and drill four
φ8 expansion rubber plugs in the four holes. Finally, place the gun holder on
the wall, align the fixing holes of the gun holder with the wall holes, and fasten
them with φ5 tapping screws.
●
The installation position of the charger shall not be close to dangerous locations
or areas such as water, oil and gas pipelines；
The installation position shall be convenient for charging, the wiring length shall
be shortened to reduce the energy consumption of cable resistance when
laying lines；
The wall hanging parts and shall be fixed with screws. The installation wall shall
be able to bear the gravity of the charger and its accessories, and shall not tilt
after installation. The wall should not be too close to the internal line；
The protection degree for indoor installation shall be at least TYPE 4, and that
for outdoor installation shall be at least TYPE 4. It is recommended that the
charger be installed in an environment with sunshade or umbrella; The lighting
and passage at the installation site of the charger must be safe and smooth；
A certain operating space shall be reserved for the installation of charger
to facilitate the overhaul and maintenance of engineering personnel；
It is recommended that the customer install a circuit breaker at the front end of
the charger. The mini circuit breaker should meet local regulations.
●
●
●
●
●
●
AC Operating Voltage: Refer to page 6；
AC Operating Frequency: Refer to page 6；
The capacity of the power supply system shall be greater than the maximu
moperating power of the product;
For the specification of power socket, please refer to Specification and
Configuration Table of Switch Socket on page 8.
●
●
●
●
A
C
D
E
F
B
［A］
［B］
［C］
［D］
［E］
［F］
Wall
Charging Pile
φ7 Wall Hole
φ8 Expandable Rubber
Stopper
Fixing Cover
φ5 Self-tapping screw
［A］
［B］
［C］
［D］
［E］
φ7 Wall Holes
φ8 Expandable
Rubber Stopper
Wall
Gun Holder
φ5 Self-tapping
screw
