4-6 Saving and Recalling Measurements IA Spectrum Analyzer (Option 24)
4-12 PN: 10580-00447 Rev. H Spectrum Analyzer MG
Recalling a Measurement
You can recall a saved setup, native trace measurement, and a limit line. When recalling a setup, the
instrument setup and operating state will be restored as it was when the setup was saved. When recalling a
trace measurement, the instrument setup and on-screen measurement data will be restored as it was when the
trace data was saved.
To recall a measurement or setup, refer to Figure 4-10:
1. Select FILE > RECALL...
2. Select the file location.
3. Use the file type filter to shorten the list if needed.
4. Select the desired file from the displayed list.
5. Select OPEN to recall the file.
When a measurement is recalled, the trace or sweep state will be set to hold. To restore active measurements,
disable SWEEP > HOLD and/or set TRACE > MODE > Active.
Figure 4-10. File Open Dialog
