2.13 Spectrum Emission Mask
2-579
2
SCPI Device Message Details
Table 2.13-1 Device messages for Spectrum Emission Mask measurement (Cont’d)
Function Device Message
Spectrum Emission
Mask Fail Logic
[:SENSe]:SEMask:LOGic:OFFSet[1]:LIST:TEST
<logic_1>[,<logic_2>[,<logic_3>[,<logic_4>[,<logic_5>[,<logic_6>[
,<logic_7>[,<logic_8>[,<logic_9>[,<logic_10>[,<logic_11>[,<logic_
12>]]]]]]]]]]]
[:SENSe]:SEMask:LOGic:OFFSet[1]:LIST:TEST?
:CALCulate:SEMask:LOGic:OFFSet[1]:LIST:TEST
<logic_1>[,<logic_2>[,<logic_3>[,<logic_4>[,<logic_5>[,<logic_6>[
,<logic_7>[,<logic_8>[,<logic_9>[,<logic_10>[,<logic_11>[,<logic_
12>]]]]]]]]]]]
:CALCulate:SEMask:LOGic:OFFSet[1]:LIST:TEST?
Spectrum Emission
Mask Configure
:CONFigure:SEMask
Spectrum Emission
Mask Initiate
:INITiate:SEMask
Spectrum Emission
Mask Fetch
:FETCh:SEMask[n]?
Spectrum Emission
Mask Read
:READ:SEMask[n]?
Spectrum Emission
Mask Measure
:MEASure:SEMask[n]?
Spectrum Emission
Mask Root Nyquist
Filter State
[:SENSe]:SEMask:FILTer[:RRC][:STATe] ON|OFF|1|0
[:SENSe]:SEMask:FILTer[:RRC][:STATe]?
Spectrum Emission
Mask Result Type
DISPlay:SEMask:RESult:TYPE PEAK|MARGin
DISPlay:SEMask:RESult:TYPE?
Title Entry
:DISPlay:SEMask:ANNotation:TITLe:DATA <string>
:DISPlay:SEMask:ANNotation:TITLe:DATA?
Log Scale Range
:DISPlay:SEMask:WINDow[1]:TRACe:Y[:SCALe]:PDIVision <rel_ampl>
:DISPlay:SEMask:WINDow[1]:TRACe:Y[:SCALe]:PDIVision?
Reference Level
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RLEVel <real>
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RLEVel?
Page Number
:DISPlay:SEMask:VIEW[1]:WINDow[1]:PAGE:NUMBer <integer>
:DISPlay:SEMask:VIEW[1]:WINDow[1]:PAGE:NUMBer?
Trigger Source
:TRIGger:SEMask[:SEQuence]:SOURce
EXTernal[1]|IMMediate|WIF|RFBurst|VIDeo|SG|BBIF|FRAMe
:TRIGger:SEMask[:SEQuence]:SOURce?
Average Count
[:SENSe]:SEMask:AVERage:COUNt <integer>
[:SENSe]:SEMask:AVERage:COUNt?
Storage Mode
[:SENSe]:SEMask:AVERage[:STATe] ON|OFF|1|0
[:SENSe]:SEMask:AVERage[:STATe]?
Couple Ref&ATT
[:SENSe]:SEMask:RACouple OFF|ON|0|1
[:SENSe]:SEMask:RACouple?
