4
Excellent Expandability
All-in-One Support for Evaluating Next-Generation NRZ/PAM4 Network Interfaces and High-Speed Serial Buses
The Signal Quality Analyzer–R MP1900A is a modular Bit Error Rate Tester (BERT) supporting equipment external interfaces, such as next-generation
Ethernet, by installing a pulse pattern generator (PPG) for outputting high-quality multi-channel NRZ/PAM4 signals over a wide bandwidth, a high-
sensitivity input error detector (ED), Jitter modulation sources for Jitter Tolerance tests, etc.
Additionally, optional noise generation and 10Tap Emphasis functions can be installed for Voltage Noise Tolerance tests, etc., and installing the
High-Speed Serial Data Test Software software enables efficient design evaluation for increasingly faster PCIe, USB, Thunderbolt, SAS and DP receivers.
NIC, Controllers
& HBAs
Storage device
SSD
PCI Express Switch
Server/Storage Racks
MP1900A
Link Training
LTSSM Analysis
Jitter Tolerance
PCI Express
Gen 1 to 5
SAS-3/-4
100 GbE
200 GbE
400 GbE
800 GbE
28G NRZ/PAM4
56G NRZ/PAM4
Network Racks
Optical Transceivers
Serdes, Gear Box
Ethernet
Evaluation
PCI Express
Evaluation
One Unit Supporting Evaluation of
both High-Speed Network Devices and High-Speed Serial Buses
MP1900A
High Cost Performance
Space Factor Improvement
Shorter Inspection Time
