ORIGINAL OPERATING INSTRUCTIONS - ELECTRIC DRIVE FOR PEDELECS
34
cassette (sprocket set) has to be properly assembled. For the
tightening torque of the cassette, please follow the manufac-
turer’s specifications.
When fastening the impeller, make sure the moulded part of the torque
supports (both side) is turned downwards, that the axis fits correctly inside
the fork (front wheel motor) / back end (rear wheel motor). The tightening
torque of the axle nuts is 25Nm.
25Nm
correct torque support
direction
