ORIGINAL OPERATING INSTRUCTIONS - ELECTRIC DRIVE FOR PEDELECS
www.ansmann.de
47
ENGLISH
Because there is an internal freewheel in the motor you could use this
electric bicycle also completely without the battery (or with switched off
battery) similar like a regular bicycle. A higher force while pedaling is then
not necessary.
16. TECHNICAL DATA
MOTOR brushless DC motor (with gear)
Voltage 36V
Current max. 12A
Power
250W (nominal continuous power)
400W (peak power)
Control
6 motor assist level up to 25km/h
Pushing aid function up to 6km/h
Torque up to 30Nm
Weight
FM4.0 approx. 1.8kg
RM5.0 approx. 2.0kg
BATTERY Lithium-Ion battery
Model 10INR18/65-4 or 10INR18/65-5
Capacity from 9.0Ah (324Wh) to 17.5Ah (630Wh)
Cells type 18650, 40 cells (10S4P) or 50 cells (10S5P)
Weight depends on the model from 2.4kg to 3.4kg
CHARGER
Lithium-Ion battery charger with CC/CV-method
Input 100-240Volt AC
Output 42Volt DC, 1.4A or 2.35A
