CAUTION
This manual should be carefully read by all individuals who have or will have responsibility for using, maintaining or servicing the product.
The Detector is not field-repairable due to the meticulous alignment and calibration of the sensors and the respective circuits. Do not
attempt to modify or repair the internal circuits or change their settings, as this will impair the system's performance and void the Ansul
Incorporated product warranty.
INTRODUCTION
The Model 20/20MI-32-S-F is a Triple IR spectrum flame detector designed to provide maximum fire protection. It uses innovative tech-
nology of advanced digital signal processing to analyze the dynamic characteristics of fire. Three sensitive IR channels process the
signals. Detection performance is controlled by a microprocessor and easily adapted to all environments, applications and requirements.
The result is a unique and superior flame detector, which provides excellent detection sensitivity with extreme immunity to false alarm.
Although there are more than one basic model of the 20/20MI Triple IR flame detector and each has numerous features, only the models
20/20MI-32-A-F* and 20/20MI-32-S-F features are applicable to vehicle fire protection using the CHECKFIRE SC-N detection module.
Only the 20/20MI-32-S-F features are addressed in this manual.
APPROVALS
20/20MI-32-A-F:
Aluminum housing, FM Approved
20/20MI-32-S-F: Stainless steel housing; FM Approved
* 20/20MI is the base detector model number. Additional numbers and letters represent options:
20/20MI-3
= Short Range (8.2-33 ft.) (2.5-10m)
20/20MI-32
= Plug Outlet
20/20MI-32-S
= Stainless Steel Housing
20/20MI-32-S-F
= FM Approved
I
NTRODUCTION
7
-1-07 Page 1
REV. 1
