Ansul SharpEye 20/20MI-32-S-F User Manual

P
ERFORMANCE
7
-1-07 Page 4
REV. 1
FIGURE 2: FLAME DETECTOR ASSEMBLY – OUTLINE DRAWING
WITH CONNECTOR OUTPUT
2
PERFORMANCE
2.1 DETECTION SENSITIVITY
Detection sensitivity is the detection distance for a specified size of fire and type of fuel ("Standard Fire") within a given time from
the ignition of the fire.
Standard Fire:
A
1 ft
2
/(0.1 m
2
) Gasoline pan fire with max. wind speed of 6.5 ft/sec/(2 m/sec).
Sensitivity Range:
The sensitivity is factory set at 10 (33 ft. (10 m)) with a response time of 3 seconds.
VIEW A
006849
NO. 6-32UNC-2B
FOR GROUND CONNECTION
NO. 10-32UNF-2B
4 PL.
DIA .275 IN. (7 mm)
2 PL.
IR SENSOR
REFLECTOR
STATUS LED
IR SENSOR
IR SENSOR
A
4
.3 IN.
(110 mm)
2.5 IN.
(63.5 mm)
2.6 IN.
(65.5 mm)
3
.9 IN.
(98.6 mm)
3.9 IN.
(98.6
mm)
