Ansul SharpEye 20/20MI-32-S-F User Manual

P
ERFORMANCE
7
-1-07 Page 6
REV. 1
2.3 FALSE ALARM PREVENTION
The detector will not provide an alarm or a warning signal as a reaction to the radiation sources specified below.
NOTES:
IAD = Immune at Any Distance
All sources are chopped from 0 to 20 Hz.
T
able 2-3.1: Immunity to False Alarm Sources
Table 2-3.2: Welding Immunity Distance – 20/20MI-32-S-F
RADIATION SOURCE IMMUNITY DISTANCE FT (M)
Sunlight IAD
Indirect or reflected sunlight IAD
Incandescent frosted glass light, 100 W IAD
Incandescent clear glass light, rough service, 100 W IAD
Fluorescent light with white enamel reflector, standard office or shop, 40 W (or two 20 W) IAD
Electric arc [12mm (15/32 in) gap at 4000 V alternating current, 60 Hz] IAD
Arc welding [4 mm (5/32 in) rod; 240 A] See Table 2-3.2
Ambient light extremes (darkness to bright light with snow
, water, rain, desert glare and fog) IAD
Bright colored clothing, including red and safety orange. IAD
Electronic flash (180 watt-seconds minimum output) IAD
Movie light, 625 W quartz DWY lamp (Sylvania S.G.-55 or equivalent) 6.5 (2)
Flashlight (MX 991/U) IAD
Radiation heater, 1500 W IAD
Radiation heater, 1000 W with fan IAD
Quartz lamp (1000 W) 10 (3)
Mercury vapor lamp IAD
Grinding metal IAD
Lit cigar 1 (0.3)
Lit cigarette 1 (0.3)
Match, wood, stick including flare up 10 (3)
SENSITIVITY DETECTION RANGE IMMUNITY DISTANCE
10
33 ft
(10 m)
>10 ft
(3 m)
