W-508
Step 1. Place the machine on a flat, level hard and well ventilated surface area and reserve at least 50 cm open
space around the machine, and make sure there is no flammable gas or material nearby;
Step 2. Fill the fluid tank with Antari approved fog fluid;
Step 3. Plug the machine to the power outlet. Please read the technical label on the back of the machine and make
sure the power outlet has the correct rated voltage for the machine;
Step 4. Turn on the power, the machine starts to warm up and the button on the handle will show red blinking
light. The warming process takes approximately 2 minutes. Once the machine has reached its operating
temperature, the red blinking light will turn solid. Now the machine is ready for operation;
Step 5. To start fogging, please press the button on the handle. To stop fogging, please release the button the
handle;
Step 6. Or refer to “10. WTR-10 Wireless Remote” for wireless operating instruction;
Step 7. To turn off the power, please make sure the machine is not operating. If you will not use the machine a
long period of time, please unplug the power cord.
W-510
Step 1. Place the machine on a flat, level hard and well ventilated surface area and reserve at least 50 cm open
space around the machine, and make sure there is no flammable gas or material nearby;
Step 2. Fill the fluid tank with Antari approved fog liquid, and make sure the tube is not twisted;
Step 3. Plug the machine to the power outlet. Please read the technical label on the back of the machine and make
sure the power outlet has the correct rated voltage for the machine;
Step 4. Turn on the power, the machine starts to warm up and the indicator light on the back of the machine will
show red blinking light. The warming process takes approximately 13 minutes. Once the machine has
reached its operating temperature, the green indicator light on the back will turn solid. Now the machine
is ready for operation;
Step 5. refer to “10. WTR-10 Wireless Remote” for wireless operating instruction;
Step 6. To turn off the power, please make sure the machine is not operating. If you will not use the machine a
long period of time, please unplug the power cord.
8. Control Settings
W-508/W-510 Wireless Fog Machine can be operated in the following modes. The machine can only accept 1 type
of signal at a time.
W-508
 Manual
 Wireless
W-510
 DMX512
 Wireless
9. DMX Function (W-510 Only)
9.1 DMX Connector Pin Assignment
This machine has a XLR 5-Pin connector for DMX connection. The diagram below indicates pin assignment
information;
