6
Pin
Function
1
Ground
2
Data-
3
Data+
**There is a protection cap on DMX IN, please
remove it with your finger before operation.
9.2 DMX Channel Function
Channel Mode
DMX Value Range
Function
Channel 1
Fog
0 – 5
Off
6 – 255
100%
9.3 DMX Addressing
Each device occupies 1 channel. To ensure that the control signals are properly directed to each device, they require
addressing. This is to be adjusted for every single device by changing the DIP-switches as set out in the table
below. The starting address is defined as the first channel from which the device will respond to the controller.
Please make sure that you do not have any overlapping channels in order to control each device correctly and
independently from any other fixture on the DMX data link.
Occupation of the DIP-switches:
Setting the DMX-
Starting Address
DIP-Switch
No.
1
2
3
4
5
6
7
8
9
Device Number &
Channels
Staring Address
1
2
4
8
16
32
64
128
256
Device 1 – Channel 1
On
▲
Off
▽
▽
▽
▽
▽
▽
▽
▽
Device 2 – Channel 2
On
▲
Off
▽
▽
▽
▽
▽
▽
▽
▽
Device 3 – Channel 3
On
▲
▲
Off
▽
▽
▽
▽
▽
▽
▽
Device 4 – Channel 4
On
▲
Off
▽
▽
▽
▽
▽
▽
▽
▽
Device 5 – Channel 5
On
▲
▲
Off
▽
▽
▽
▽
▽
▽
▽
10. WTR-10 Wireless Remote (Standard)
WTR-10 Wireless Remote is a standard accessory for W-508/W-510 Wireless Fog Machine, it included a W-1
wireless transmitter and a W-1 wireless receiver (Already on the machine) and it’s ready to use. If you encounter
any problem, please contact your local Antari dealer for assistant.
