4.4 O PTIONAL F ANS
The LanBoy Air can accommodate up to ten additional 120 mm fans in four different locations:
1. Two additional fans can be mounted inside the left larger panel.
2. Three fans can be mounted inside the left smaller panel
3. Three fans can be mounted inside the right smaller panel
4. Two fans can be mounted at the top of the chassis.
Optional fan mounts on the LanBoy Air:
A –2 x 120 mm large side panel fans
B – 6 x 120 mm small side panel fans (3 x per side)
C – 2 x top 120 mm fans
When installing optional top-mounted fans, use the top fan mounting screws identified in section 1.3. When installing
optional side-mounted fans, use the side fan mounting screws identified in section 1.3.
4.5 W ATER C OOLING
The LanBoy Air is water cooling-ready. Removing the rear handle at the top of the
LanBoy Air allows a water cooling radiator to be installed. In addition, water cooling
grommets have been provided at the back of the chassis to accommodate water cooling.
Note: We recommend using Antec 120mm TriCool™ or TwoCool™ fans and setting the speed to Low. All fans
bring cool air into the chassis, which creates positive air pressure, pushing heat and dust out of the chassis.
A
B
C
Figure 34 – Water cooling grommets
