Antec Mini Skeleton-90 - Table of Contents

1
T ABLE OF C ONTENTS
I NTRODUCTION
1.1 Case Specifications……………………………………………………………………………………….. 3
1.2 Diagram………………………………………………………………………………………………………… 3
1.3 EP-90 Power Supply Specifications……………………………………………………………….. 4
H ARDWARE I NSTALLATION G UIDE
2.1 Removing/Replacing the Component Tray…………………………………………………… 5
2.2 Motherboard Installation……………………………………………………………………………… 5
2.3 5.25” Device Installation………………………………………………………………………………. 6
2.4 2.5” Device External Installation…………………………………………………………………… 6
2.5 2.5” Device Frame-Mounted Installation……………………………………………………… 7
2.6 Removing the Frame Side Screen Panels………………………………………………………. 7
C ONNECTING THE F RONT I/O P ORTS
3.1 USB 2.0 Ports………………………………………………………………………………………………… 8
3.2 Audio Ports…………………………………………………………………………………………………… 8
3.3 Power Switch / Reset Switch / Hard Disk Drive LED Connectors……………………. 9
C OOLING S YSTEM
4.1 150mm Overhead TriCool™ Fan.………………………………………………………………….. 10
4.2 70mm Intake Fan……………………………………………………………………………………….. 10
