Anybus X-gateway - 3 Installation; 3.1 DIN Rail Mounting

Configuration 11 (14)
The slave I/O map is also reflected in the input and output data exchange buffers of the
PROFIBUS master interface:
Slave Input Data Slave Output Data
Anybus NetTool for PROFIBUS can be downloaded from www.anybus.com/support, where you
will also find additional documentation and configuration examples.
Anybus
®
X-gateway
™
PROFIBUS Master Interface Network Guide
SCM-1202-104 1.0 en-US
