Technical Data 12 (14)
5 Technical Data
5.1 Technical Specifications
PROFIBUS functionality
Complete Profibus DP Master functionality according to IEC 61158
Optional Live List of the active status of the connected slaves
Maximum number of slaves
125
Maximum I/O data
512 bytes in each direction
Supported baud rates
Automatic baudrate detection up to 12 Mbit/s
Configuration method Anybus Configuration Manager via serial port (RS-232)
PROFIBUS connector
1 x D-sub 9-pin female
Configuration port 1 x D-sub 9-pin male
Anybus
®
X-gateway
PROFIBUS Master Interface Network Guide
SCM-1202-104 1.0 en-US
