Product Overview
FRONT VIEW
②
③
④
⑤
①
① PWR Power LED. LED is on when turn on the Router.
② WAN WAN LED, LED is on when linking to DSL/Cable Modem.
③ INT Internet connection LED. LED is on when the router connect to internet. WAN settings of the
Router is needed. Blinking means data communication between the Router and internet.
④ W-LAN Wireless LAN LED. LED is on when turning on the Router.
⑤ LAN 1/2/3/4 LAN LED, LED is on when the Router connect to NIC of LAN side PC with LAN cable.
Blinking means data communications between the Router and LAN side PC.
4
