Anyload T15 Series - CHAPTER I INTRODUCTION; 1.1 FEATURES AND SPECIFICATION

CHAPTER
I INTRODUCTION
1.1 FEATURES AND SPECIFICATION
Features:
 Large LCD display (digit height 30mm x 13mm) with LED backlight
 Kilogram (kg), and pound (lb) weighing modes
 Application include: simple counting , hold, accumulation
 Low power indication and auto power off
Options:
 RS-232 or Serial printer
Specifications ：
Load Cells
Minimum 350 ohm load cells
Maximum 1000 ohm
(Up to 4 load cells of 350 ohm)
Readability
Selectable, 0.0
Tare Function
Full
Units of
measure
Kg , lb
Power supply
Rechargeable battery or AC adaptor DC 9V
Connector
4 pin d socket
1. Load cell connection:
2. RS-232 connection:
·2- pin = Data output (TXD)
·5- pin = Ground (GND)
3. printer connection:
2
5
3
