13. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice. Please go
to http://cs.tpv.com.cn/hello1.asp
for the latest information.
TIAASPNE6WA1UNE
Location Part No. Description Remark
040G 58162435A P/N LABEL FOR MANUAL PE BAG
052G 1186 SMALL TAPE
052G 1208 A ALUMINIUM TAPE
052G 1211 B Conductive Tape 85mm *40mm *0.09mm
052G 2191 A PAPER TAPE
E07801 078G0020 2 V SPEAKER 4 OHM 2 W 430/230mm 40X20mm
E08907 095G179J30NE15 FFC CABLE 30PIN P1.0MM 206MM 2nd source
E09503 095G8014 7DE13 HARNESS 7P(2008)-6P(1615) 500
E09503 095G8014 7TE13 HARNESS 6P-7P(2008) 500 2nd source
E09503 095G8014 7WE13 HARNESS 7P(2008)-6P(1615) 500 2nd source
0D1G1730 8120 SCREW
0M1G 130 6120 SCREW M3X6
705GH934025 21.5"LCD STAND-BASE ASS'Y
E750 750GAU215H10LHN000 LCD M215HW01 V0TL WH AUO
A15G0647I02 MAIN_FRAME
A34G1160AEDB1B0130 BEZEL
A34G1161AEDA2S0100 REAR COVER21.5"
A85G0140201MCM AC Shield
H40G 58161569A USB LABEL
H40G 58361562A SRS B-VISTA LABEL
H41G780061586B QSG
H44GB005102 EPS
H44GB005202 EPS
H44GB005615 2D CARTON
H45G 77 6 PE PACKING
H45G 87 18 12 EPE_COVER_MONITOR
H70G2009615 7E CD MANUAL
Q45G 76 28 H A PE BAG FOR MANUAL
Q45G 76 28V13 A PE BAG
Q50G 4 10 TIE (Y1900221)
Q52G 1185 99 big carton tape for aoc
Q52G6019 14 TAPE
E08907 S95G179T30NE15 FFC CABLE 30PIN P1.0MM 206MM
705GH934025 21.5"LCD STAND-BASE ASS'Y
0Q1G1740 12120 SCREW
A34G1064AED 1S0100 Stand-Front
A34G1065ABJ 1S0100 Stand-Back
A34G1162AED 2S0130 BASE
A37G0108 3 Hinge
H01G6006 1 Screw
756GHACB A1106 MAIN BOARD-CBPCASPA1H3
SMTCA-U402 100GAMAI038W11 MCU ASS'Y-056G1133137
808G2236SWAHKG 2236SWA HongKong ASS'Y
E08904 089G 173 56 4B AUDIO CABLE
E08905 089G 175 8A C USB CABLE 1800MM without PE bag
E08905 089G 175 8A G USB CABLE 1800MM without PE bag 2nd source
E08902 089G 715CAAE01 SIGNAL CABLE 2nd source
E08902 089G 715GAAE01 SIGNAL CABLE 2nd source
