AOC 24V2Q User Manual

25
Picture Boost
1 Press MENU (Menu) to display menu.
2 Press or to select (Luminance), and press to enter.
3 Press or to select submenu.
4 Press or to adjust.
5 Press to exit.
Bright Frame
ON/OFF
Enable/Disable Bright Frame
Frame Size
14-100
Adjust the Size of the Frame
Brightness
0-100
Brightness Adjustment for Enhance Area
Contrast
0-100
Contrast Adjustment for Enhance Area
H. position
0-100
Adjust the horizontal position of the Frame
V. position
0-100
Adjust the vertical position of the Frame
Note:
Adjust the brightness, contrast, and position of the Bright Frame for better viewing experience.

AOC 24V2Q Specifications

General

Screen Size	23.8 inches
Resolution	1920 x 1080 (Full HD)
Panel Type	IPS
Refresh Rate	75 Hz
Response Time	5 ms
Aspect Ratio	16:9
Brightness	250 cd/m²
Contrast Ratio	1000:1
Viewing Angles	178°/178°
Inputs	1 x HDMI 1.4, 1 x DisplayPort 1.2, 1 x VGA
Color Gamut	NTSC 72%
