AOC CQ27G1 User Manual

28
Monitor Is Stuck In Active
Off-Mode"
The Computer Power Switch should be in the ON position.
The Computer Video Card should be snugly fitted in its slot.
Make sure the monitor's video cable is properly connected to the computer.
Inspect the monitor's video cable and make sure no pin is bent.
Make sure your computer is operational by hitting the CAPS LOCK key on
the keyboard while observing the CAPS LOCK LED. The LED should either
turn ON or OFF after hitting the CAPS LOCK key.
Missing one of the primary
colors (RED, GREEN, or
BLUE)
Inspect the monitor's video cable and make sure that no pin is damaged.
Make sure the monitor's video cable is properly connected to the computer.
Screen image is not centered
or sized properly
Adjust H-Position and V-Position or press hot-key (AUTO).
Picture has color defects
(white does not look white)
Adjust RGB color or select desired color temperature.
Horizontal or vertical
disturbances on the screen
Use Windows7/8/10 shut-down mode to adjust CLOCK and PHASE.
Press to auto-adjust.

AOC CQ27G1 Specifications

General

Panel type	VA
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Backlight type	W-LED
Display diagonal	27 \
Screen curvature	1800 mm
Adobe RGB coverage	75 %
Display technology	LED
Native aspect ratio	16:9
Screen curvature rating	1800R
Viewable size, vertical	335.664 mm
sRGB coverage (typical)	102 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.736 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	2560 x 1440
Tilt angle range	-4 - 21.5 °
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SER
Certification	ISO
Product color	Black
Market positioning	Gaming
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (typical)	23 W
Mean time between failures (MTBF)	50000 h
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Package depth	473 mm
Package width	694 mm
Package height	250 mm
Package weight	8083 g
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	30 - 144 Hz
Cables included	DisplayPort, HDMI

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	535 mm
Weight (with stand)	6110 g
Width (without stand)	612 mm
Height (without stand)	366.6 mm
Weight (without stand)	4580 g
