AOC CQ32G1 User Manual

6
Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and
use mounting accessories recommended by the manufacturer. A product and cart combination should be moved
with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a fire or
electric shock. Never spill liquids on the monitor.
Do not place the front of the product on the floor.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a fire or damage to the monitor.
See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or with
the stand:
10cm
4 inches

AOC CQ32G1 Specifications

General

3D	No
Panel type	VA
Color depth	8 bit
Pixel pitch	0.2724 x 0.2724 mm
Backlight type	W-LED
Display surface	Matt
Display diagonal	32 \
Screen curvature	1800 mm
Adobe RGB coverage	92 %
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 146 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	1080p, 1440p
Screen curvature rating	1800R
Viewable size, vertical	392.256 mm
sRGB coverage (typical)	119 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	697.344 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
Tilt angle range	-4 - 21.5 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
HDMI version	1.4/2.0
DisplayPort version	1.2
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
Certification	ISO
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Cables included	AC, DisplayPort, HDMI
HDMI cable length	1.8 m
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	52 W
Sustainability certificates	RoHS
Package type	Box
Package depth	242 mm
Package width	807 mm
Package height	551 mm
Package weight	10320 g
AMD FreeSync type	FreeSync Premium
AMD FreeSync refresh rate range	30 - 144 Hz
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	244.86 mm
Width (with stand)	713.11 mm
Height (with stand)	530.34 mm
Weight (with stand)	7280 g
Depth (without stand)	81.75 mm
Width (without stand)	425.35 mm
Weight (without stand)	5670 g
